JBK-1100 Automatic Card Mounting Machine

JBK-1100 Automatic Card Mounting Machine

A new type of Feida vacuum paper conveyor is set up with face paper and bottom paper respectively, and overlapping paper feeding method is adopted to make the paper feeding process more stable and accurate.

Share:

JBK-1100 Fully Automatic Cardboard Laminating Machine,using new type feeder vacuum paper guide to face paper and body paper separately,and adopting overlap paper feed way,so paper feed process are more steady and precise.Pasting to the body paper is based on different surface paper requipment,so we can adjust thickness system,even if the machine is running,the pasting will still keep thinner and evener,therefore,it achieves effevts of increasing work efficiency and saving glue water.Couple high strength grip paper compound roller to locate,paste ,first press the face and body paper ,then the two paper will be pressed  four times by strong pressing in roller to delivery stacker,at last the products will be piled in three sided even way,and height of the piled papers can reach 1650mm. machine combines the advantages of manual and automatic,reducing "human cost",improve efficiency, more "economic, reasonable, high quality, high efficiency".

This machine adopts Siemens PLC programmable controller,multipoled pressure,automatic control hydraulic station.The finished product is not only precise in laminating,but also very firm and even.Meanwhile,they will directly enter into next process such as die cutting without glue drying.Automatic production and high dfficiency greatly reduce output cost,can help company create considerable benefit.This automatic production and high efficiency greatly reduce output cost,can help company create considerable benefit. This automatic production line is applied to manufacture garment hangtag、wine box、shoes box、food box and so on, it will inevitably help company and improve economic performance.
